Equipment Description
1. Side seal-packing method, valve piston pump filling meter.
2. Film disinfection.
3. The finished packed products are elegant and reliable, hygiene and security.
4. Assembled with a photoelectric controller to ensure that its packing bag figure are perfect.
5. It can automatically finish making-bag, metering, filling, sealing, cutting, counting and printing batch number.
6. The body and the parts touching the material are made of stainless steel.
PARAMETER
| Model | HL-BF1000 |
| Bag making length | 50-150 mm |
| Bag making width | 65-150 mm |
| Packing film width | 150-320 mm |
| Packing capacity | 50-550 ml |
| Packing speed | 1100-1300 bags/h |
| Power | 2.1 Kw |
| Overall Dimension | 1050*850*2050 mm |
| Weight | 370 Kg |
